Delivering breath-taking scope for creativity, the DJM-750 takes FX manipulation and software synergy to new levels. The DJM-750 combines our latest audio and FX technology in an attractively priced 4-channel mixer. The mixer boasts 13 Beat FX with a dedicated Level/Depth knob for tactile control of the wet/dry mix.
The DJM-750 inherits the same 32-bit digital signal processor as our club-standard DJM-900NXS and a built-in 24-bit/96 kHz USB sound card, while 3 sampling rates makes it perfect for production and recording.
Boost Color FX lets you engage and control Sound Color FX and Beat FX all in one movement. Hitting the Boost FX button adds another layer of FX to the Sound Color FX, and you can manipulate the parameters of both FX together depending on how fast you twist the large chrome knob.
A built-in USB sound card allows simultaneous input/output of stereo signals from 4 ins and 4 outs, while 96 kHz/24-bit high-sampling processing ensures the audio quality. Connect the unit to your laptop or computer via USB and the settings utility tool will automatically open, allowing you to configure the mixer, sound card and audio routing to suit your preferences.
This mixer is equipped with a 32-bit A/D converter that digitizes and enhances sound quality for all outputs, while the 32-bit digital signal processor suppresses digital noise. Even analog noise is reduced through balanced hybrid operation amps and output circuits.
When you use our rekordbox dj software, you can buy the rekordbox dvs Plus Pack to get low latency scratch control with music from your rekordbox library. Find out more
Fully assignable MIDI functionality sends control information to external devices to be used as a MIDI controller.
Use the 3-band EQ isolator to control the high, mid and low frequencies on each channel independently.
Specifications
Main Features
MIDI Control: Full assignable MIDI controls
P-LOCK Fader Caps - yes
Auto Standby - yes
Specifications
Rack Mount - yes
Frequency Range: 20 - 20000 Hz
Sampling Rate: 96 kHz
Width: 12.6 in
Height: 4.25 in
Depth: 14.8 in
Weight: 16.76 lb
A/D Converter: 24 bit
D/A Converter: 24 bit
S/N Ratio Line: 106 dB
Crosstalk Line: 82 dB
Distortion: < 0.004 %
Headroom: 19 dB
Master
Master Balance - yes
Stereo/Mono Switch - yes
Frequency Filter - yes
Level Meter Size - 15 segment
Master Out Attenuator - yes
Channels
EQ/ISO - 3 band
EQ/ISO Range –26 dB ~ +6 dB
Level Meter Type - Individual
Level Meter Size - 15 segment
Performance Control
Channels - 4
Sound Color FX
Crush
Filter
Jet
Noise
Beat FX
Delay
Echo
Filter
Flanger
Phaser
Reverb
Reverse Roll
Robot
Roll
Slip Roll
SND/RTN
Spiral
Trans
Vinyl Brake
FX Frequency
Effect Sampler
3-Band Isolator - yes
Auto BPM Counter - yes
Effect Level & Depth Volume - yes
MIDI Global Clock - yes
Roll Down - yes
Roll Up - yes
Roll Sampler (Fwd) - yes
Roll Sampler (Reverse) - yes
Crossfader
Crossfader Type: Carbon Rail with P-Lock Fader Cap
CURVE Assignable - yes
Field Replaceable - yes
Fader Curve - 3
Mic
Mic Connection
Jack
XLR
Mic EQ - 2 band
Talkover - 3 Position Switch
MIDI Info
Assignable Controls: 49
MIDI On/Off - yes
MIDI Start/Stop - yes
Sound card
Connection - USB
Stereo Inputs - 4
Stereo Outputs - 4
Sample Rate - 24 bit
Frequency - 96 kHz
Terminals
Inputs
1 MIC (XLR/Jack Combo)
2 LINE (1/4 inch Jack)
2 PHONO (RCA)
6 CD/LINE (RCA)
Send/Return
1 SEND (1/4 inch Jack)
Outputs
1 BOOTH (RCA)
1 HEADPHONE MONITOR (1/4 inch Jack)
1 REC OUT (RCA)
1 S/PDIF Digital (RCA)
2 CONTROL (Mini-jack)
2 MASTER (XLR, RCA)
USB
1 USB B port
