Full-size LED strip light functions as a pixel mapping effect, uplight, or for great eye-candy effects
-
ILS compatibility for use in the ILS ecosystem
-
Create dazzling effects by linking multiple units together to make runway chases
-
D-Fi USB compatibility for wireless Master/Slave or DMX control (D-Fi™ USB sold separately)
-
Create amazing animations and video effects with individual LED control
-
Ideal for quiet applications due to silent operation and no moving parts
-
Wireless, non-DMX operation is available with the optional IRC-6 remote
-
Easily transports in the optional CHS-60 VIP Gear Bag
Specifications
- DMX Channels: 3, 8, 120, 122
- DMX Connectors: 3-pin XLR
- Light Source: 40 LEDs (tri-color) 2 W, (0.8A), 50,000 hours life expectancy.
- Strobe Rate: 0 to 20 Hz
- Beam Angle: 14°
- Field Angle: 24°
- Illuminance: 4,967 lux @ 2 m
- Lumens:1,491
- Power Linking: 7 units @ 120 V; 10 units @ 230 V
- Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
- Power and Current:
79 W, 1.2 A @ 120 V, 60 Hz
77 W, 0.8 A @ 230 V, 50 Hz - Weight:6.2 lb. (2.8 kg)
- Size: 38.9 x 2 x 6.2 in (987 x 49 x 157 mm)
- Approvals: CE, ROHS
- Cable Length: 5 ft (1.52 m)
- Bracket Mounting Hole: 13mm
- Optional Controllers: IRC6, ILS Command
What's Included
- COLORstrip Pix ILS
- Power cord
- Quick Reference Guide
